Features:
●Die-cast aluminium body ensures excellent heat dissipation
●High efficiency aluminum reflector with glass
●COB options: Citizen, Cree and Epistar
●Remote drivers: Non-dimmable, DALI or 1-10V on request
●IP20, Ta25, CRI>80
●Superior thermal performance, leading to a longer life
Installation:
Recess mounted
Key Applications:
Shopping Centers, Supermarkets, Office buildings, hotels, etc.
|
Photometric: |
Drawing: |
 |
 |
|
Product Code |
Wattage |
Diameter ? (mm) |
Cutout ? (mm) |
Height (mm) |
Lumen @4000K (lm) |
CCT (K) |
CRI |
Power Factor |
Carton Size (cm) |
Qty/ctn (pcs) |
|
MQT-LED-0310K |
10w |
115 |
100 |
113 |
850lm |
3000-6500K |
>80 |
>0.9 |
53x27x40 |
24 |
|
MQT-LED-0415K |
15w |
145 |
130 |
127 |
1400lm |
3000-6500K |
>80 |
>0.9 |
50x30x32.5 |
12 |
|
MQT-LED-0520K |
20w |
175 |
160 |
140 |
1800lm |
3000-6500K |
>80 |
>0.9 |
56x38x33.5 |
12 |
|
MQT-LED-0625K |
25w |
190 |
175 |
150 |
2250lm |
3000-6500K |
>80 |
>0.9 |
62x42x35.5 |
12 |
|
MQT-LED-0630K |
30w |
190 |
175 |
150 |
2700lm |
3000-6500K |
>80 |
>0.9 |
62x42x35.5 |
12 |
|
MQT-LED-0845K |
45w |
235 |
220 |
170 |
4050lm |
3000-6500K |
>80 |
>0.9 |
50x50x38.5 |
8 |
